| Battery |
12pcs 3DG-250(250Ah@5hr rate) |
| Motor Power |
5KW Chinese motor |
| Controller |
Curtis 1205M 400A@2minutes) |
| Passenger capacity |
6 |
| Range (loaded) based on flat road at a speed of 20km/h (km) |
>50 |
| Max. speed(km/h) |
25 |
| Minimum turning radius (m) |
7 |
| Max. climbing ability |
10% |
| Max. loading weight |
1000kgs |
| Overall dimensions (mm) |
5600*2200*2750 |
| Body and Frame |
|
| Frame |
Welded steel framework with phsophating treatment |
| Body |
Fibreglass, double-deck, with insulating material in the middle |
| Driver’s seat |
Adjustable |
| Windshield |
Front laminated glass, side safety glass |
| Battery box |
Metal, sliding |
| Floor |
Bamboo + artificial leather |
| Side rear view mirror |
Two pieces per cart |
| Electric system |
|
| Lighting system and horn |
Front headlight and turning light, rear led taillight (including brake light and turning light), inner dome light |
| Dashboard |
Voltameter, ammeter, speedometer, turn signal indicator, headlight indicator, emergency switch, fog light switch; Headlight switch, turn signal switch, wiper switch, horn button; |
| Charger |
China origin, input 110V-240V~50Hz-60Hz, output 72V, 25A ,offboard |
| Switch assembly |
Lights switch, horn switch, wiper switch |
| LED screen |
At the front |
| Audio System |
Radio and MP3 receiver |
| Speaker |
4pcs |
| Power cable and receptacle |
For household power connection |
| Power meter |
for household power recording |
| Safety switch |
for household power |
| Inside office equipment |
|
| Office table |
with marble table-board |
| Air-condition |
for cooling and heating, 1.5P |
| Refrigeratory |
50L onboard |
| Outdoor public Broadcasting |
Power amplifier |
| Printer |
Colorful |
| Steering and Suspension |
|
| Steering system |
Recirculating ball steering gear, with electrical power assistant steering system |
| Brake system |
Four wheel hydraulic drum brake+hand parking, with vacuum booster |
| Drive system |
5F+1R gear box, with clutch |
| Suspension |
leaf spring + hydrualic shock absorber |
| Tyre |
6.00-14, 2 in the front and 4 in the rear |
